Philips Semiconductors
UM_1SPP
BGB203 BT 2.0 Serial Port Profile Module User’s Guide
6.
V.25 Commands
The following section describes the V.25 commands that are supported. Each command
will be described in detail below. This detail will include the command format, command
parameters and command responses. Each command also will include examples to
show how the command can be used.
I – Information
Description:
This command returns the information identification string about the
current product.
Format:
ATI
Results:
Result will be one (or more) lines of product information, followed by the
result code (either OK or ERROR ).
Example:
ATI
1SPP – Ver: 1.1
OK
E – Echo
Description:
This command configures the device to either echo received characters
in command mode (or not to echo received characters in command
mode).
Format:
ATE<X>
where,
<X> is a single ASCII Digit:
0 – disable echo
1 – enable echo
Results:
Result will be the result code
OK
ERROR
It should be noted that command responses will still be generated when
commands are processed (when echo is disabled).
Example:
ATE0
OK
Z – Reset configuration to default
Description:
This command is used to restore the current configuration settings back
to internal default values (not values that are stored into Flash and/or
Factory Settings).
Format:
ATZ
Results:
? Koninklijke Philips Electronics N.V. 2005
All rights are reserved. Reproduction in whole or in part is prohibited without the prior
written consent of the copyright owner. The information presented in this document does
not form part of any quotation or contract, is believed to be accurate and reliable and may
be changed without notice. No liability will be accepted by the publisher for any
consequence of its use. Publication thereof does not convey nor imply any license under
patent- or other industrial or intellectual property rights.
Date of release:21 Dec 2005
Published in The Netherlands
